Adjustable Welding Rotator

Adjustable Welding Rotator

Description of Adjustable Welding Rotator:

Our HGK-type adjustable welding rotator is designed for handling and automatic welding circular metal containers, and it mainly used in oil industry, press vessel field, wind tower production line, pipe line production field, and many other round workpiece fields.
It is mainly composed of a drive rotator, an idle rotator, an electric control box, and a remote control box. The drive rotator owns two sets of movable rolling wheels and bases. The base has a box structure to protect the inside screw components, and the base can also connect the two movable drive rotators. By rotating the screw, the two sets of rolling wheels can simultaneously move forward or backward. This adjustable welding rotator is connected with an electric motor through a worm gear speed reducer. The drive rotator can offer stable rotating power to ensure the operation efficiency, and the electric control box is fitted with a digital display screen, on which accurate rotating speed of the rotator is shown.
This adjustable welding rotator is designed and manufactured to better meet increasing demands for pressure vessel manufacturers, so it enjoys more advantages over other similar products at home and abroad. It can be used to deal with a wide range of diameters. It features easy operation, high quality, low noise, advanced technology, etc.
Besides, this rotator has obtained CE certificate, and is quite popular among clients in Brazil, India, Jordan, South Africa, UK, Poland, Spain, etc.

Technical Parameters of Adjustable Welding Rotator:

Type		HGK-2	HGK-5	HGK-10	HGK-20	HGK-40	HGK-60	HGK-100	HGK-200	HGK-300	HGK-500
Load		2	5	10	20	40	60	100	200	300	500
Wheel diameter(mm)		250	250	300	350	450	500	550	700	800	900
Wheel width(mm)		100	160	196	210	220	200(metal)	220(metal)	300(metal)	300(metal)	300(metal)
Vessel diameter	MIN(mm)	150	250	300	500	500	500	800	800	1000	1000
	MAX(mm)	2000	2800	3200	4500	4800	5000	5000	5000	6000	8000
Wheel velocity(m/h)		6-60	6-60	6-60	6-60	6-60	6-60	6-60	6-60	6-60	6-60
Power of motor(kw)		2*0.18	2*0.37	2*0.55	2*1.1	2*1.5	2*2.2	2*3	2*4	2*5.5	2*7.5

Wuxi ABK Machinery Co.Ltd is a professional manufacturer of adjustable welding rotator in China. And we can also provide our clients around the world with many other products including special welding rotator, wind tower production line, H beam welding line, pipe welding equipment, CNC cutting machine, grinding machine, roll forming machine, plate bending machine, etc. We have obtained ISO and CE certification, and we also offer OEM service. Our products have been well received by customers from many countries, such as Spain, India, Germany, South Africa, Brazil, Chile, Argentina, Russia, Italy, France, Vietnam, and more. If you're interested in our adjustable welding rotator, please don't hesitate to contact us whenever you want.
